Pre-bituminised asphalt grids

S&P Carbophalt® G 200/200

Carbon fibre asphalt reinforcement grid


S&P Carbophalt® G 200∕200 is a pre-bituminised asphalt reinforcement grid made of carbon fibres for local and/or complete surface reinforcement of bituminous surfaces.


  • Measurable improvement of the structural value due to high tensile strength at small elongation
  • Minimises crack formation and prevents crack reflection
  • Prevents fatigue cracks
  • The pre-bituminisation guarantees the required layer bonding between old and new road surfaces (no fixed knots)
  • Lower consumption of tack coat thanks to the pre-bituminised grid
  • Easy and efficient application with unrolling equipment (also in curves)
  • No waiting time - immediate road construction possible
  • Can be milled and recycled without problems
  • Reduces maintenance costs


  • Increases the load bearing capacity of asphalt surfaces
  • Surface reinforcement on roads where the layer height is limited
  • Local application on existing cracks/joints or complete surface application
  • Effectiveness at a cover layer of min. 2 cm

Logistic Data

Logistical Data

Width of roll 1.95 m (further on request)
Length of roll 50 m

Installation Instructions

Installation Instructions

- Apply S&P Carbophalt® G 200∕200 on dry surface, either by machine or manually, and if possible immediately before the installation of the road surface
- Apply at temperatures > 3 °C. Observe relevant norms for application of layers
- Ensure overlapping lengths of 10–20 cm are observed
- Overlapping of the reinforcement mesh should be optimised, according to the nature and location of joints/cracks, as well as wheel loading
- If the mesh is applied only on local areas, it shall be covered manually with an asphalt layer. This prevents cracking caused by passing vehicles.
- Minimum covering of 2 cm above S&P Carbophalt® G 200∕200

Unrolling equipment is available on a rental basis. S&P will assist and/or carry out the work if requested.
